TC 100 THERMOHYGROMETER
TC 100 THERMOHYGROMETER
The TC100 is a multifunctional diagnostic device for professional climate control and quickly detects the WBGT index, such as in the assessment of heat-stressed workplaces. For adjusted measurements in indoor and outdoor areas, the direct solar radiation can be calculated by function or can remain ignored. Likewise, an individual WBGT alarm limit can be defined, the exceeding of which is immediately indicated acoustically. In addition, the TC100 is able to determine practically all relevant parameters for climatic comfort.
STANDARD FEATURES
- For assessing the heat load or standard-compliant comfort measurement at the workplace according to ISO 7243, ISO 7726 and DIN 33403
- Fast reaction time
- Zeroing function
- Offset setting for radiant heat, air temperature and humidity
- Data Hold, Min, Max and Alarm functions
- Data memory for 99 measured values
- Display lighting
- ¼-inch thread for tripod mount
- In addition to battery and mains operation for continuous measurements possible
- Energy-saving car shutdown
- Including calibration certificate
Other Features
Air temperature:
- Measuring range: 0 ° C to 50 ° C (32 ° F to 122 ° F)
- Accuracy: ± 0.6 ° C
- Resolution: 0.1 ° C
Humidity:
- Measuring range: 0 to 99.9% r.F.
- Accuracy: ± 3% at 25 ° C and 10 to 70% RH, otherwise ± 5%
- Resolution: 0.1% r.F.
Radiant heat (Black Globe):
- Measuring range: 0 ° C to 80 ° C (32 ° F to 176 ° F)
- Accuracy: ± 0.6 ° C at 20 ° C to 50 ° C, otherwise ± 1 ° C
- Resolution: 0.1 ° C
Climate (WBGT):
-
- Measuring range inside / outside: 15 ° C to 59 ° C / 15 ° C to 56 ° C
- Accuracy inside / outside: ± 1 ° C at 15 to 59 ° C, otherwise ± 1.5 ° C at 15 to 56 ° C, otherwise ± 2 ° C
- Resolution: 0.1 ° C
