Additel 673

Additel 673

STANDARD FEATURES
Additel 673

Additel 673

Other Features

Accuracy ADT673-02: 0.02% of full span
ADT673-05: 0.05% of full span
673-RD: 0% to 20% of Range: 0.02% of full span, 20% to 110% of Range: 0.1% of reading, Vacuum: 0.25% of full span[1][2]
Barometric Accuracy (built-in barometer) 50Pa
Gauge Types Gauge pressure, compound pressure, absolute pressure, differential pressure
Display Color Touchscreen (capacitive)
Screen protector: tempered glass film (replaceable)
Display rate: 3 readings per second (Default setting). Adjustable from 10 readings per second to 1 reading every 20 seconds
Resolution: 4,5 or 6 digits (user selectable)
Pressure Units Pa, kPa, MPa, psi, bar, mbar, kgf/cm2, inH2O@4°C mmH2O@4°C, inHg@0°C, mmHg@0°C and 5 customizable units
Environmental Compensated Temperature: 14°F to 122°F (-10°C to 50°C)
Operating Temperature: 14°F to 122°F (-10°C to 50°C)
Storage Temperature: -4°F to 158°F (-20°C to 70°C)
Humidity: 0 – 95%, Non-condensing
