3mm, 4 Microplate Light Duty Orbital Shaker

3mm, 4 Microplate Light Duty Orbital Shaker

Dependable OHAUS Light Duty Shakers are designed for applications with loads up to 4 kg. Choose from two orbits and speed ranges to optimize your sample mix. One digital model dedicated for use with microplates, two digital models designed to work with accessories and a non-digital economical unit for everyday shaking. All models feature triple eccentric drive systems for stable shaking with microprocessor-control for reliable shaking action.

Max. load capacity (with platform) is 7.5kg
A wide choice of platforms for various applications
Over-load and over-speed detection and protection
LED display for easy-reading of speed and time simultaneously
Fashion design of high strength tempered glass on the front panel
Automatic alarm by time controller allows for unsupervised operation
Brushless DC motor is maintenance-free and provides long service life
Continuous operation and timing operation in range of 0- 99h59min are available
Supports both orbital shaking and linear shaking and easy to switch the shaking mode
Digital speed control system and micro-computer control make stable running and prevent sample splashing


Other Features

Shaking motion     Orbital / Linear
Motor type Brushless        DC motor
Max. load capacity(with platform)[kg]    7.5
Orbital diameter [mm]    10
Speed display    LED
Speed range[rpm]     20-500
Time display    LED
Time range    0-99h59min
Operation type     Continuous / timing operation
Permissible ambient temperature[°C ]    5-40
Permissible relative humidity     80%
Protection class acc. to DIN EN60529    IP21
Voltage [VAC]      100-240
Frequency [Hz]    50/60
Power [W]     40
Dimensions [W x D x H, mm]     450 x 400 x 105
Weight [kg]    11
